Dalsa Genie Nano Series User Manual

72 • On-Semi Sensor Models Nano Series GigE Vision Camera
Gain Control In-sensor Analog Gain (1.0x to 8x) in 11 gain steps
(1.0, 1.14, 1.33, 1.6, 2.0, 2.29, 2.67, 3.2, 4.0, 5.33, 8.0)
In-sensor Digital Gain (1x to 32x) in 0.01x steps
In-FPGA Digital Gain (1x to 4x) in 0.007x steps
Binning Support
Yes In-FPGA
(summing and average,
2x2, 4x4 )
Yes In- Sensor
(averaging 2x2)
No
Color Correction Support No Yes
Decimation Support No
Defective Pixel Replacement Yes, up to 512 positions
Image Correction Yes, Sensor FPN correction feature
Image Flip Support Yes, In-Sensor, Vertical Only
Multi-ROI Support Yes, in Sensor, up to 16 ROI (mutually exclusive with binning)
On-Board Image Memory 90MB
Output Dynamic Range (dB) 61.8 dB (in 10-Bit Pixel Format)
SNR (dB) 39.7 dB (in 10-Bit Pixel Format)
*TurboDrive internal limitation of 250MB/sec
† Note: The actual internal minimum exposure may be different than what is programmed. Use the feature
“exposureTimeActual” from the
Sensor Control category to read back the actual sensor exposure. The exposure start
sensor event is delayed 4 µs from the actual start.
