Dalsa Genie Nano Series User Manual

130 • Operational Reference Nano Series GigE Vision Camera
Counter1End Event Counter1End Select the CounterEnd Event as the internal trigger
source.
Trigger Input Line Activation TriggerActivation Select the activation mode for the selected Input
Line trigger source. This is applicable only for
external line inputs.
1.00
Beginner
Rising Edge RisingEdge The trigger is considered valid on the rising edge of
the line source signal (after any processing by the
line inverter module).
Falling Edge FallingEdge The trigger is considered valid on the falling edge
of the line source signal (after any processing by
the line inverter module).
Any Edge AnyEdge The trigger is considered valid on any edge of the
line source signal (after any processing by the line
inverter module).
Level High LevelHigh The trigger is considered valid on the high level of
the line source signal.
Level Low LevelLow The trigger is considered valid on the low level of
the line source signal.
Trigger Delay TriggerDelay Specifies the delay in microseconds to apply after
receiving the trigger and before activating the
triggerEvent. (min=0, max=2000000)
1.00
Beginner
Trigger Overlap TriggerOverlap States if a trigger overlap is permitted with the
Active Frame readout signal. This feature defines if
a new valid trigger will be accepted (or latched) for
a new frame.
1.00
Guru
Off Off No trigger overlap is permitted.
ReadOut ReadOut Trigger is accepted immediately after the start of
the readout.
End Of Exposure EndOfExposure Trigger is accepted immediately after the previous
exposure period. This will latch the Trigger and
delay the Exposure if the end of that exposure is
shorter than the previous readout.
Line Selector LineSelector Selects the physical line (or pin) of the external
device connector to configure.
1.00
Beginner
Line 1 Line1 Index of the physical line and associated I/O
control block to use. Pin 5 is the Input Signal and
Pin 3 is the common Ground on the I/O connector.
Line 2 Line2 Index of the physical line and associated I/O
control block to use. Pin 7 is the Input Signal and
Pin 3 is the common Ground on the I/O connector.
Line 3 Line3 Index of the physical line and associated I/O
control block to use. Pin 6 is the Output Signal and
Pin 4 is the common output power on the I/O
connector.
Line 4 Line4 Index of the physical line and associated I/O
control block to use. Pin 8 is the Output Signal and
Pin 4 is the common output power on the I/O
connector.
Line 5 Line5 (Optional Model – see Output3 below) Index of the
physical line and associated I/O control block to
use. Pin 9 is the Output Signal and Pin 4 is the
common output power on the I/O connector.
Line Name lineName Description of the physical Pin associated with the
logical line.
1.00
Beginner
DFNC
Input 1
Input 2
Input1
Input2
Associated with the logical line Input 1
Associated with the logical line Input 2
* “G3-GM2… or G3-GC2…” part numbers denote
optional “1 input / 3 output” special order models.
Output 1
Output 2
Output 3
Output1
Output2
Output3
Associated with the logical line Output 1
Associated with the logical line Output 2
* “G3-GM2… or G3-GC2…” part numbers denote
optional “1 input / 3 output” special order models.
