Danfoss Turbocor VTT Series User Manual

131 of 165
M-SV-VT-001-EN Rev. A
Compressor Components
Description Nm Ft.Lb. In.Lb.
Power Cover, SHCS, M5x16 6 - 53
Service Side Cover, SHCS, M5x16 6 - 53
Power Cable Nut, Brass M10x1.5 10 8 89
Rear Bearing Power Feed Through, SHCS, M6x20 6 - 53
Rear Bearing Sensor Feed Through, SHCS, M6x20 6 - 53
Stator Temperature Sensor Feed Through, SHCS, M6x20 6 - 53
End Cap, SHCS, M12x55 70 52 620
Axial Bearing Assembly, SHCS, M8x40 30 22 266
Stator Cooling Temperature Sensor, SHCS, M4x20 4 - 35
Thrust Disk, SHCS, M5x35 10 7 88
Radial Bearing Assembly, SHCS, M8x65 30 22 266
Table 31 - Internal
Components Torque
Specications
3.7.2.2.3 Torque
Specications
