Compressor Components
3.7.1.8 Rear Bearing
Sensor Cable
Figure 99 - Rear Bearing
Sensor Cable
The Rear Bearing Sensor Cable provides shaft position information from the Rear Bearing Sensor Feed
Through to the CCM. The Rear Bearing Sensor Cable also receives a signal from the Stator Cooling
Temperature Sensor.
5
6
7
4
8
3
9
2 1
10
11
5
2
3
7
8
4
9
6
1
Figure 97 - 9-Pin Connector
Figure 98 - Feed Through
Connector
