138 of 165 M-SV-VT-001-EN Rev. A
Variable Frequency Drive Components
4.5 VFD Pressure Control
Valve Cable
The VFD Pressure Control Valve Cable connects the CIM to the VFD Pressure Control Valve Motor.
Figure 176 - VFD Pressure
Control Valve Cable
4.5.1 VFD Pressure
Control Valve Pin
Connections
Figure 177 - VFD Pressure
Control Valve Pin
Identication
