Table 37 - Motor
Terminal Block Torque
Specications
Compressor Removal and Installation
Description Nm Ft.Lb. In.Lb.
Power Cover, SHCS, M5x16 6 - 53
Service Side Cover, SHCS, M5x16 6 - 53
Power Cable Nut, Brass M10x1.5 10 8 89
Ground Screw 6 - 53
Ground Cable Nut, M10x1.5, Brass 20 15 177
Suction Flange, SHCS, M20x2.5 6 5 53
Discharge Flange, SHCS, M20-2.5 6 5 53
Economizer Flange, SHCS, M16x2 20 15 177
Motor Cooling Exit Flange, SHCS, M14x2 10 8 89
Motor Cooling Inlet Flange 5 4 44
Base Mounting, SHCS, M12x1.75 20 15 177
7.3.1 Torque
Specications
