Danfoss Turbocor VTT Series User Manual

161 of 165
M-SV-VT-001-EN Rev. A
Appendix B: Special Tooling Specifications
R1.5 x 4
125
A
52.25
40.022 ±0.013
B
0.05 A B
0.10
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
6.4
TOLERANCES:
WHOLE No.s: 0.5
ONE DECIMAL PLACE: 0.1
2 DECIMAL PLACES: 0.05
ANGULAR: 0.5
Figure B1 - Volute Assembly Sleeve
