Wiring
Danger
Wiring must be performed by authorized and ◆
qualified personnel. Risk of danger.
Circuit-breaker should be installed between ◆
inverter and the mains. Risk of fire.
Make sure the input power supply has been ◆
completely disconnected before wiring. Failure to
comply may result in personnel injury and/or
equipment damage.
Since overall leakage current of this equipment ◆
may be bigger than 3.5mA, for safety's sake, this
equipment and its associated motor must be well
grounded so as to avoid risk of electric shock.
Never connect the power cables to the output ◆
terminals (U, V, W) of the AC drive. Pay attention
to the marks of the wiring terminals and ensure
correct wiring. Failure to comply will result in
damage to the AC drive.
Install braking resistors at terminals (P+)and ◆
(P- or PB) only. Failure to comply may result in
equipment damage.
