Dell PowerConnect PC5524

Spanning-Tree Commands 477
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\Spanning-Tree.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
• mst-configuration —Displays the MST configuration identifier.
•
interface-id —Specifies an interface ID. The interface ID can be one of
the following types: Ethernet port or Port-channel.
Command Mode
Privileged EXEC mode
Example
The following examples display spanning-tree information.
Console# show spanning-tree
Spanning tree enabled mode RSTP
Default port cost method: long
Loopback guard: Disabled
Root ID Priority
Address
Path Cost
Root Port
32768
00:01:42:97:e0:00
20000
gi1/0/ 1
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Bridge ID Priority
Address
36864
00:02:4b:29:7a:00
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
