Managing networks and connections Analyze data traffic
Digi TransPort® Routers User Guide
891
Serial Interfaces
Interface Value
Serial 0 1
Serial 1 2
Serial 2 4
Serial 3 8
Serial 4 16
Serial 5 32
Serial 6 64
Serial 7 128
Serial 8 256
Serial 9 512
Serial 10 1024
Serial 11 2048
Serial 12 4096
To enable the Analyser on multiple serial interfaces, add the appropriate values together. For
example, to enable the Analyser on serial interfaces 2 and 3, the value should be 12 (4+8).
The number of serial interfaces can vary on different depending on which hardware and software
options are available.
Raw Sync Interfaces
Interface Value
ISDN D 1
ISDN B1 2
ISDN B2 4
Physical Port 0 8
Physical Port 1 16
To enable the Analyser on multiple serial interfaces, add the appropriate values together. For
example, to enable the Analyser on Physical Ports 0 and 1, the value should 24 (8+16).
