C HAPTER 21 | LLDP-MED Commands
– 458 –
EXAMPLE
LLDPMED>info
Local port : Port 7
Device Type : Network Connectivity
Capabilites : LLDP-MED Capabilities, Network Policy, Location
Identification, Extended Power via MDI - PSE
Application Type : Voice
Policy : Defined
Tag : Tagged
VLAN ID : 50
Priority : 6
DSCP : 46
Location : Country code:US -- National subdivsion:CA --
City:Roseville -- Street:Foothills -- House No.:
8000 -- Unit:R3L
LLDPMED>
lldpmed
debug_med_transm
it_var
This command shows or sets the current value of the global
medTansmitEnable variable (Section 11.2.1, TIA 1057).
SYNTAX
lldpmed debug_med_transmit_var [port-list] [enable | disable]
port-list - A specific port or a range of ports. (Range: 1-28, or all)
enable - Sets medTansmitEnable variable to true.
disable - Set medTansmitEnable variable to false.
DEFAULT SETTING
Disabled
EXAMPLE
LLDPMED>debug_med_transmit_var 2 enable
LLDPMED>
