HAPTER

| UPnP Commands

– 481 –

EXAMPLE

UPnP>ttl 255

UPnP>

upnp advertising

duration

This command displays or sets the advertising duration of UPnP messages.

SYNTAX

upnp advertising duration [duration]

duration - The duration, carried in Simple Service Discover Protocol

(SSDP) packets, which informs a control point or control points how

often it or they should receive a SSDP advertisement message from

this switch. Due to the unreliable nature of UDP, the switch sends

SSDP messages periodically at the interval one-half of the

advertising duration minus 30 seconds. (Range: 100-86400

seconds)

DEFAULT SETTING

100 seconds

EXAMPLE

UPnP>advertising duration

UPnP>
