6.2.3 SMPTE Packages
Note: The audio selection should reflect the audio package in number of audio channels.
• You can change the Template Mapping setting by clicking on the list-menu and selecting
the desired setting (Figure 24).
• Make sure to click the Save button to ensure the configuration is saved (Figure 23).
• The list of possible labels that can be routed (if present in the audio MXF file) are defined by
SMPTE as follows:
• L/Left
• R/Right
• C/Center
• LFE Screen
• Ls/Left surround
• Rs/Right surround
• Lc/Left center
• Rc/Right center
• Cs/Center surround
• Rrs/Right rear surround
• Lrs/Left rear surround
• HI/Hearing Impaired
• VI-N/Visual Impaired-Narration
6.2.4 Interop Packages
Interop audio MXF files do not contain any channel label information. Therefore, if a configuration
is selected, the routing will be executed as if the audio MXF file was created according to the
ISDCF audio mapping recommendations, which currently consists of:
Figure 34: ISDCF – Interop Recommendations
______________________________________________________________________________________
D2K.OM.001822.DRM Page 34 of 177 Version 1.5
