dSPACE DS1103 User Manual

Connector (P1) Pin Sub-D Pin Signal Pin Sub-D Pin Signal
P1 65 P1B 28 GND P1 66 P1A 28 GND
P1 67 P1B 12 SADCH1 P1 68 P1A 12 SADCH2
P1 69 P1B 45 GND P1 70 P1A 45 GND
P1 71 P1B 29 SADCH3 P1 72 P1A 29 SADCH4
P1 73 P1B 13 GND P1 74 P1A 13 GND
P1 75 P1B 46 SADCH5 P1 76 P1A 46 SADCH6
P1 77 P1B 30 GND P1 78 P1A 30 GND
P1 79 P1B 14 SADCH7 P1 80 P1A 14 SADCH8
P1 81 P1B 47 GND P1 82 P1A 47 GND
P1 83 P1B 31 SADCH9 P1 84 P1A 31 SADCH10
P1 85 P1B 15 GND P1 86 P1A 15 GND
P1 87 P1B 48 SADCH11 P1 88 P1A 48 SADCH12
P1 89 P1B 32 GND P1 90 P1A 32 GND
P1 91 P1B 16 SADCH13 P1 92 P1A 16 SADCH14
P1 93 P1B 49 GND P1 94 P1A 49 GND
P1 95 P1B 33 SADCH15 P1 96 P1A 33 SADCH16
P1 97 P1B 17 GND P1 98 P1A 17 GND
P1 99 P1B 50 SADCSOC P1 100 P1A 50 GND
Because the pin numbering used for Sub-D connectors is not
standardized, the following illustrations show the numbering scheme
used (viewed from the top of a female connector)
Do not rely on the numbers written on Sub-D
connectors.
Pinout of Sub‑D connectors
s
Connector Pinouts and LEDs
t
110
s
DS1103 Hardware Installation and Configuration November 2014
