Signal Channel/Bit Numbers of Related RTI Blocks/RTLib Functions I/O Pin on …
Related RTI Block(s) Ch/Bit
(RTI)
Related RTLib Functions Ch/Bit
(RTLib)
DS1103 Sub‑D
Conn.
CP/CLP
ADCH17 DS1103ADC_Cx Ch 17 See ADC Unit ( DS1103
RTLib Reference)
Ch 17
(conv 5)
P1 35 P1B 23 CP17
ADCH18 Ch 18 Ch 18
(conv 6)
P1 36 P1A 23 CP18
ADCH19 Ch 19 Ch 19
(conv 7)
P1 39 P1B 40 CP19
ADCH20 Ch 20 Ch 20
(conv 8)
P1 40 P1A 40 CP20
DAC Unit
n Output voltage range: ±10 V
n Output current range: ±5 mA
n DACH1 … DACH8: D/A converter output
n I/O circuit and further electrical characteristics: see Analog Outputs on page 165
DACH1 DS1103DAC_Cx Ch 1 See DAC Unit ( DS1103
RTLib Reference)
Ch 1 P1 47 P1B 25 CP21
DACH2 Ch 2 Ch 2 P1 48 P1A 25 CP22
DACH3 Ch 3 Ch 3 P1 51 P1B 42 CP23
DACH4 Ch 4 Ch 4 P1 52 P1A 42 CP24
DACH5 Ch 5 Ch 5 P1 55 P1B 10 CP25
DACH6 Ch 6 Ch 6 P1 56 P1A 10 CP26
DACH7 Ch 7 Ch 7 P1 59 P1B 27 CP27
DACH8 Ch 8 Ch 8 P1 60 P1A 27 CP28
s
Signal Mapping to I/O Pins
t
