Signal Channel/Bit Numbers of Related RTI Blocks/RTLib Functions I/O Pin on …
Related RTI Block(s) Ch/Bit
(RTI)
Related RTLib Functions Ch/Bit
(RTLib)
DS1103 Sub‑D
Conn.
CP/CLP
Bit I/O Unit
n TTL voltage range
n Output current range: ±10 mA
n I/O circuit and further electrical characteristics: see Bit I/O on page 168
IO0 DS1103BIT_IN_Gx/
DS1103BIT_IN8_Gx/
DS1103BIT_OUT_Gx/
DS1103BIT_OUT8_Gx
Group 1
bit 0
See Bit I/O Unit ( DS1103
RTLib Reference)
Bit 0
(group 1)
P2 5 P2B 18 CP30 1
IO1 Group 1
bit 1
Bit 1
(group 1)
P2 6 P2A 18 CP30 18
IO2 Group 1
bit 2
Bit 2
(group 1)
P2 7 P2B 2 CP30 2
IO3 Group 1
bit 3
Bit 3
(group 1)
P2 8 P2A 2 CP30 19
IO4 Group 1
bit 4
Bit 4
(group 1)
P2 11 P2B 19 CP30 3
IO5 Group 1
bit 5
Bit 5
(group 1)
P2 12 P2A 19 CP30 20
IO6 Group 1
bit 6
Bit 6
(group 1)
P2 13 P2B 3 CP30 4
IO7 Group 1
bit 7
Bit 7
(group 1)
P2 14 P2A 3 CP30 21
IO8 Group 2
bit 0
Bit 8
(group 2)
P2 17 P2B 20 CP30 5
IO9 Group 2
bit 1
Bit 9
(group 2)
P2 18 P2A 20 CP30 22
IO10 Group 2
bit 2
Bit 10
(group 2)
P2 19 P2B 4 CP30 6
IO11 Group 2
bit 3
Bit 11
(group 2)
P2 20 P2A 4 CP30 23
IO12 Group 2
bit 4
Bit 12
(group 2)
P2 23 P2B 21 CP30 7
IO13 Group 2
bit 5
bit 5
Bit 13
(group 2)
P2 24 P2A 21 CP30 24
IO14 Group 2
bit 6
Bit 14
(group 2)
P2 25 P2B 5 CP30 8
IO15 Group 2
bit 7
Bit 15
(group 2)
P2 26 P2A 5 CP30 25
s
Mapping of I/O Signals
t
142
s
DS1103 Hardware Installation and Configuration November 2014
