Signal Channel/Bit Numbers of Related RTI Blocks/RTLib Functions I/O Pin on …
Related RTI Block(s) Ch/Bit
(RTI)
Related RTLib Functions Ch/Bit
(RTLib)
DS1103 Sub‑D
Conn.
CP/CLP
Synchronizing I/O Features of the Master PPC
n TTL input voltage range
n I/O circuit and further electrical characteristics: see Slave DSP Bit I/O on page 171
ST1PWM * DS1103SYNC_IO_SETUP/
DS1103MASTER_SYNCINT
See Synchronous I/O Trigger
( DS1103 RTLib Reference)
P2 59 P2B 27 CP31 23
Slave DSP ADC Unit
n Input voltage range: 0 … 5 V
n SADCH1 … SADCH16: input for A/D converter with 10‑bit resolution
n I/O circuit and further electrical characteristics: see Slave DSP Bit I/O on page 171
SADCH1 * DS1103SL_DSP_ADC_Cx Ch 1 See Slave DSP ADC Unit
( DS1103 RTLib Reference)
Ch 1 P1 67 P1B 12 CP29 20
SADCH2 * Ch 2 Ch 2 P1 68 P1A 12 CP29 21
SADCH3 Ch 3 Ch 3 P1 71 P1B 29 CP29 22
SADCH4 Ch 4 Ch 4 P1 72 P1A 29 CP29 23
SADCH5 Ch 5 Ch 5 P1 75 P1B 46 CP29 24
SADCH6 Ch 6 Ch 6 P1 76 P1A 46 CP29 25
SADCH7 Ch 7 Ch 7 P1 79 P1B 14 CP29 26
SADCH8 Ch 8 Ch 8 P1 80 P1A 14 CP29 27
SADCH9 * Ch 9 Ch 9 P1 83 P1B 31 CP29 28
SADCH10 * Ch 10 Ch 10 P1 84 P1A 31 CP29 29
SADCH11 Ch 11 Ch 11 P1 87 P1B 48 CP29 30
SADCH12 Ch 12 Ch 12 P1 88 P1A 48 CP29 31
SADCH13 Ch 13 Ch 13 P1 91 P1B 16 CP29 32
SADCH14 Ch 14 Ch 14 P1 92 P1A 16 CP29 33
SADCH15 Ch 15 Ch 15 P1 95 P1B 33 CP29 34
SADCH16 Ch 16 Ch 16 P1 96 P1A 33 CP29 35
s
Mapping of I/O Signals
t
146
