Setting the folding station plate
102 Service Instructions 755 A/756 A - 00.0 - 02/2019
Information
The position of the ratchet lever (2) has been set at the factory and is fixed
with 2 clamping pins (Ø 2 mm). If a correction is necessary, the clamping
pins need to be hammered out.
4. Use suitable means to hammer out the clamping pins.
5. Loosen the screws (1).
6. Set the distance between the extended surface of the folding station
plate (5) and the needles to 87 mm.
7. Tighten the screws (1).
8. Re-attach the plate of the ratchet lever (2) using pins.
To do so, use new clamping pins and the 2 unused
holes on the plate of the ratchet lever (2).
