Stacker
240 Service Instructions 755 A/756 A - 00.0 - 02/2019
Fig. 234: Assembling the pincer stacker (3)
8. Lay the pneumatic line of the throttle valves (9) to pneumatic
valve Y25 (7).
Lay the pneumatic line to the throttle valves (9) to pneumatic
valve Y26 (6).
Route the pneumatic lines through the pincer stacker stand and fix
them in place using cable ties.
Fig. 235: Assembling the pincer stacker (4)
9. Lay the grounding wires (10) and (11) from the pincer stacker to
the stand.
(8) - Throttle valves (9) - Throttle valves
⑧⑨
(10) - Grounding wire (11) - Grounding wire
â‘©
⑪
â‘©
⑪
