Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 299

Creating a seam program

 The display switches to Create seam program.

Fig. 284: Creating a seam program

Press a button to either open another submenu or enter the desired values

directly using the numeric keypad.
