Programming

308 Service Instructions 755 A/756 A - 00.0 - 02/2019

Correction light barrier

 The display switches to Correction light barrier.

Fig. 290: Correction light barrier.

To make a correction to the light barrier:

1. Press the desired button.

2. Enter the desired value using the numeric keypad.

3. Confirm with OK.

Symbols Meaning

Set correction light barrier seam begin.

• -20 mm - +20 mm

Set correction light barrier seam end

• -20 mm - +20 mm
