DURKOPP ADLER 755 A

Needle bar
Service Instructions 755 A/756 A - 00.0 - 02/2019 31
Fig. 18: Aligning the needle bar with the throat plate (4)
5. Turn the needle bar linkage (3) such that the needles are at the center
of the needle holes (5).
6. Tighten the screw (1).
(3) - Needle bar linkage (6) - Needle holes
⑤③
