Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 375

Information

The arrows in the left half of the display indicate the correction direction.

Seam beginning

Correction inward (smaller angle)

Correction outward (greater angle)

Seam end

Correction outward (greater angle)

Correction inward (smaller angle)
