Programming

410 Service Instructions 755 A/756 A - 00.0 - 02/2019

External devices

 The display switches to External devices.

Fig. 376: External devices

Addr DevName Meaning

3 DIOExt Digital IO card

5 BobbCrt Remaining thread monitor

6 St2Ext Corner knife station: Slant activation seam beginning/seam end

7 St2Ext Corner knife station: Angle adjustment seam beginning left/right

8 St2Ext Corner knife station: Angle adjustment seam end left/right

9 St2Ext Outfeed roller/tape feeder

: St2Ext Laser adjustment
