Super G3/G3 Multi Fax Board
For printers that can use multiple fax lines by adding the optional Super G3/G3 Multi Fax Boards, you can send a
fax while receiving a fax, receive multiple faxes at the same time, or send faxes at the same time.
Expansion Fax Ports
A
EXT. port Making Settings When You Connect a Phone Device. This is for standard
faxing.
B
LINE1 port Connect the printer to the phone line. This is for standard faxing.
C
LINE3 port Connect the printer to the phone line. The method for connecting the port is
the same as for the LINE1 port. For details, see the related Information below.
D
LINE2 port
Fax Settings Menu (When Optional Fax Boards Installed)
When you install the Optional Fax Boards, the following menus are added.
Aer
adding a fax line, make settings
for the added menus according to how the lines will be used.
Note that you cannot connect an external telephone to the added line.
Basic Settings (When Optional Fax Boards Installed)
You can nd the menu on the printer's control panel below.
Settings > General Settings > Fax Settings > Basic Settings
Using Optional Items
>
Super G3/G3 Multi Fax Board
>
Fax Settings Menu (When Optional Fax Boards Installed)
374
