134 Eos Apex, Eos Ti, Gio, Gio @5, Ion Xe, Ion Xe 20, and Element 2 User Manual
Note:
Channel and Parameters filters can also be used with Global Effects Faders.
See Global Effects Fader (on page400)
Note:
For presets and palettes, channel and parameter filters can only be assigned
in the fader configuration display (Tab 36) or in the fader list (Tab 35).
For cue lists and submasters, channel and parameter filters can be set in the following areas:
Cue List Index
Submaster List
Fader configuration display (Tab 36)
Fader list (Tab 35)
In Live using the {Properties} softkey
Tap or click on {Chan Filter} to assign channels or groups. Tap or click on {Param Filter} to
open a list of available parameters that you can filter. Only the specified channels, groups, and
parameters will be played back.
Note:
Filters will travel with their assigned cue lists and submasters wherever they
are mapped.
When a filter has been applied, an indicator will display in the fader ribbon. C will display for
channel filter, and F is for parameter filter.
Clearing Channel and Parameter Filters
Press the red [X] to clear the channel or parameter filters listed.
Virtual Fader Module
A virtual fader module can be opened from the home screen by selecting the Faders display
button, or by pressing [Tab] [2][8].
The virtual fader module has a configuration menu, which is accessed by first selecting the
module tab and then double clicking on the tab to open the menu. With the virtual fader
module selected, you can also select the gear icon, which is located by the tabs, to open the
configuration menu.
The following options are available in this configuration menu:
Rows - sets the number of rows used for the module. Maximum number of rows is six.
Columns - sets the number of columns used for the module. Maximum number of
columns is six.
