284 Eos Apex, Eos Ti, Gio, Gio @5, Ion Xe, Ion Xe 20, and Element 2 User Manual
values. In addition to normal editing functions, you may also use the following commands in
this view: [Copy To], {Make Absolute}, {Make Null}, Move To(accessed by pressing [Copy To]
[Copy To]), and {Replace With}.
The following are representative methods used for editing palettes in blind spreadsheet:
•
[Color Palette] [1] [Thru] [9] [Enter] - selects color palettes 1 through 9.
•
[1] {Scroller} {Make Null} [Enter] - sets channel 1 scroller value null in the selected color
palette(s).
•
[1] {Scroller} [4] [Enter] - sets channel 1 scroller value to frame 4 in the selected color
palette(s).
Here are some examples of the additional palette editing features available in spreadsheet
view:
•
[palette type] [1] [Thru] [5] {Move To} <palette type> [9] [Enter] - this will move palettes
1 through 5 to palettes 9 through 14 respectively. You do not have to supply the end
value for the console to perform the move.
•
[Beam Palette] [1] [Thru] [5] [Enter] {Iris} [5] [0] {Replace With} [2] [5] [Enter] - for
palettes 1 through 5, this command will replace any iris parameter values of 50 with
values of 25.
Editing Palettes in List View
When you press the specific Intensity, Focus, Color or Beam palette button twice, a list view
for the associated palette type is opened in a new tab (or brings the list view into focus if
already open). You can also open the list views from the home screen. See
Workspace Layout
Menu (on page90)
for more information.
You can also open the list views by using their tab numbers. Press and hold [Tab] and type the
number to open.
•
Intensity Palette - [Tab] [2] [2]
•
Focus Palette - [Tab] [2] [3]
•
Color Palette - [Tab] [2] [4]
•
Beam Palette - [Tab] [2] [5]
Indicators for absolute (A), locked (L), and by type (T+) display to the right of the palette
number.
Note:
In the by type channels column, any channel number with an asterisk
indicates that the channel does not have any by type data stored to it.
From the list view, you can select a palette for editing, which changes focus to blind channel
view, with the specified palette ready for editing. In addition, you can add palettes to your list
and edit the labels for each palette in the list.
Example:
In the list view, you can select palettes and relabel or move them.
•
[1] [5] [Label] <name> [Enter]
While in the specific palette category list view, the {Edit} softkey is available for use. The {Edit}
softkey opens a blind channel view of the selected palette and changes focus from the palette
list. You can change the blind display to spreadsheet or table view by pressing the [Format]
key.
To copy a specific palette to a new palette:
