Show Control 601
•
Cue 3/1 is resumed. The console will send Resume Cue 3 1.
•
A sub’s bump button is held down.
•
Sub 5’s bump button is pressed down. The console will send SubDown 5.
•
A sub’s bump button is released.
•
Sub 5’s bump button is pressed down. The console will send SubUp 5.
•
A macro is fired.
•
Macro 1 is fired. The console will send Macro 1.
Note: String MIDI Tx is restricted by {MIDI Cue List} in Setup. See Show Control
Settings .
Sending UDP Strings
UDP strings will be sent from the console on an ephemeral (always changing) port number to
the destination port specified in Setup. UDP strings sent to multicast IP addresses are not
supported.
Note: The console can be configured to send either ACN strings or UDP strings, as
they share the String Tx IP Address field. A combination of device names for ACN and
IP addresses for UDP is not supported.
Sending ACN Strings
To send ACN strings, {String TX} must be enabled in Setup > System > Show Control, and the
device's IP address must be set in the {String TX IPAddress} field.
If you have multiple devices sending or receiving strings, separate each entry in the {String TX
IP Address} field with a comma or semicolon.
Note: The console can be configured to send either ACN strings or UDP strings, as
they share the String Tx IP Address field. A combination of device names for ACN and
IP addresses for UDP is not supported.
Sending via the I/O Gateway
For your console to send serial data to a Net3 I/O Gateway, the Serial Port Group ID assigned at
the gateway must match the String TX Group ID in Setup, and String TX setting in Setup must
be Enabled. See Show Control Settings .
