Show Control 613
OSC Method Arguments Examples/Comments
/eos/chan/<number>/min
number for button edge:
1.0=down, 0.0=up (optional)
/eos/chan/1/min
/eos/chan/<number>/max
number for button edge:
1.0=down, 0.0=up (optional)
/eos/chan/1/max
/eos/chan/<number>/+%
number for button edge:
1.0=down, 0.0=up (optional)
/eos/chan/1/+%
/eos/chan/<number>/-%
number for button edge:
1.0=down, 0.0=up (optional)
/eos/chan/1/-%
Set parameter or DMX information
/eos/chan/<number>/dmx number for channel DMX level /eos/chan/1/dmx=255
/eos/chan/<number>/param/
<parameter>
number for parameter level
/eos/chan/1/param/pan=90
(useful for mapping to an
OSC slider)
/eos/chan/<number>/param/
<parameter 1>/<parameter
2>/...
number for all parameter
levels
multiple numbers for each
parameter level
/eos/chan/1/param/pan/
tilt=90
(set channel 1 pan & tilt to
90)
/eos/chan/1/param/pan/
tilt=45,90
(set channel 1 pan to 45 &
tilt to 90)
/eos/chan/<number>/param/
<parameter>/dmx
number for parameter DMX
level
/eos/chan/1/param/pan/
dmx=255
/eos/chan/<number>/param/
<parameter 1>/<parameter
2>/.../ dmx
number(s) for parameter DMX
level(s)
/eos/chan/1/param/pan/tilt/
dmx=255
Channel Output Information – see Implicit OSC Output (on page630) for more information
/eos/out/active/chan
String with active channels
(selected) and current value
from first channel
/eos/out/active/chan=”1-2
[100]”
OSC Absolute Levels
Absolute level commands are used when there is an existing target already selected on the
command line of the OSC user.
OSC Method Arguments Examples/Comments
Set levels
/eos/at
number for the level (0-
100)
/eos/at= 75 (useful for
mapping to an OSCfader)
/eos/at/out
number for the button
edge 1.0=down, 0.0=up
(optional)
/eos/at/out
/eos/at/home
number for the button
edge 1.0=down, 0.0=up
(optional)
/eos/at/home
/eos/at/remdim
number for the button
edge 1.0=down, 0.0=up
/eos/at/remdim
