622 Eos Apex, Eos Ti, Gio, Gio @5, Ion Xe, Ion Xe 20, and Element 2 User Manual
OSC Method Arguments Examples/Comments
+%
/eos/fader/<index>/<fader index>/-
%
none /eos/fader/1/2/-%
Fader Status Information – see Implicit OSC Output (on page630) for more information
/eos/out/fader/<index>/<fader>/name
String
argument with
fader label for
OSC fader
/eos/out/fader/1/1=“S 1 Label”
Sub 1 with a label “Label”
/eos/out/fader/1/2=“IP 1 Label” IP
1 fader labeled “Label”
/eos/out/fader/<index>/<fader>/name
Floating point
argument for
fader percent
(0.0-1.0)
/eos/out/fader/1/1=0.75
/eos/out/fader/1/2=0.0
/eos/out/fader/<index>
String
argument,
descriptive text
for OSC fader
bank at index
/eos/fader/1=“1”
OSCKey
Note: For a list of supported key names, see Eos OSCKeys.
OSC Method Arguments Examples/Comments
/eos/key/<name>
number for button edge:
1.0=down, 0.0=up (optional)
/eos/key/select active=1.0 (press
[Select Active] but- ton)
/eos/key/select active=0.0 (release
[Select Active] but- ton)
/eos/key/go 0
(press & release [Go] button)
Note: For the slash key, use a backslash /eos/key/\
OSCAddress
OSC Method Arguments Examples/Comments
Selection
/eos/addr
number for address to
select
/eos/addr=513
Set Levels (Parks address while on the OSC command line)
/eos/addr/<address>
number for level to set
address to (0-100)
/eos/addr/513=100 (useful for
mapping to an OSC slider)
/eos/addr/<address>/dmx
number for DMX level to
set address to (0-255)
/eos/addr/513/dmx=255 (useful for
mapping to an OSC slider)
