634 Eos Apex, Eos Ti, Gio, Gio @5, Ion Xe, Ion Xe 20, and Element 2 User Manual
Device
Hardware
MIDI
Connections
MIDI Show
Control (MSC)
MIDI Time
Code (MTC)
MIDI Notes SMPTE
ETCnomad Puck
Or
Programming
Wing
In Only
Or
Programming
Wing
Out Only
Or
Programming
Wing
Only
Eos Programming
Wing
Yes, In/Out
Local
In/Out
Also via SC
GW
Local
In Only Also
via SC GW
Local
Out Only Also
via SC GW
Via SC
GW In
Only
Net3 Show
Control GW
Yes
In/Out/Thru
Yes In/Out Yes In Only Yes Out Only
Yes In
Only
Net3 I/O GW n/a n/a n/a n/a
Device Analog
Contact
Closure
Relay Out RS-232
UDP
Strings
Eos Titanium (Ti)
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
Rx & Tx
Eos Console
Via I/O
GW
Via I/O GW Via I/O GW
Via I/O
GW
Rx & Tx
Eos RPU
Via I/O
GW
Via I/O GW Via I/O GW
Via I/O
GW
Rx & Tx
Gio
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
Rx & Tx
Gio @ 5
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
Rx & Tx
Ion
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW*
Rx & Tx
Ion RPU & Eos Family
RPU3
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW*
Rx & Tx
ETCnomad (PC/Mac) and
ETCnomad Puck
Via I/O
GW
Via I/O GW Via I/O GW
Via I/O
GW
Rx & Tx
Eos Programming Wing
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
n/a
Element
Via I/O
GW
4 closures,
others via I/O
1 local SPDT,
others via I/O
Via I/O
GW
Rx & Tx
Net3 Show Control GW n/a n/a n/a n/a n/a
Net3 I/O GW
Yes
24 shared circuits- analog
or digital
Yes 16 SPDT
relays
Yes
n/a
*Ion consoles that have a DVI splitter and any Ion RPU have a local RS-232 port that is not
enabled. For questions, please contact ETC Technical Services. See Help from ETC Technical
Services (on page3) to find the office closest to you.
