3GS Technical Manual
Issue 4.5 August 2005
Programming Menus 8-85
*: The output has not been given a default value.
**: These outputs apply to Class IV systems and all software that supercedes 3GS version 5.50.
Menu
option
Function O/P no. Menu option Function O/P no.
Standard Intruder 1 Miscellaneous Mains Fault 207
External Bell 2 Battery Fault 208
Panic 3 PIN Code Alert 210
Full Set/Full Arm 4 PIN Code Duress 211
Fire 5 Installer On-Site 212
Technical Fault 6 Line Fault 213
Internal Bell 7 Raid Camera 214
System Buzzer 8 Photo Entry 215
Verified Alarm 9 Suspicion 216
Modem 10 Unset Local 250
Area Exit
Entry
Exit/EntryArea 1 to 30 11-40 Duress 251
Common Area Exit/
Entry
43 Zone Inhibit on
confirmed alarm **
O/P 252 252
Area Set/
Arm
Area 1 Set/Arm to Area
30 Set/Arm
44-73 Area Warning *Area 1 to Area 30 10m
warning
0
Part Set 74 *Full Set/Full Arm 10m
warning
0
Half Set 75 Area Detector Reset *Area 1 to Area 30 Det.
Reset
0
Common Area Set/
Arm
76 *Common Area Det.
Reset
0
Area Alarm Area 1 Alarm to Area
30 Alarm
77-106 Door Forced *Door 1 to Door 64
Forced
0
Common Area Alarm 109 Door Shunted *Door 1 to Door 64
Left Open
0
Area Bell Area 1 Bell to Area 30
Bell
111-140 Area Warning *Area 1 to Area 30 10m
warning
0
Common Area Bell 143 *Full Set/Full Arm 10m
warning
0
Area Strobe Area 1 to Area 30
Strobe
217-246 FTC FTC 255
Common Area Strobe 249 Watchdog Reset ** O/P 252 252
Area Fail to
Set/Arm
Area 1 to Area 30 Fail
to Set/Arm
144-173 Auto Start Auto Start 253
Common Area Fail to
Set/Arm
176
Area Fire-X Area 1 to Area 30 Fire-
X
177-206
Common Area Fire-X 209
