Issue 4.5 August 2005 Technical Specifications 15- 9
8 Input/Output Node
Security Grade Grade 3
SEAP Classification Class IV
Environmental class Class II indoor General
PCB dimensions 150mm x 82.5mm,
Enclosure dimensions 200mm x 153mm x 47mm
Minimum Operation Voltage 9.5V
Maximum Operating Current 200mA
Quiescent Current 100mA
8 on-board zones Dual 2K2 End Of Line resistors (1K,470 R in US)
Outputs 1 relay, single pole changeover, 1 Amp
Status LED Indicates status of communications
Tamper Front tamper provided
Auxiliary Fuse 250mA Quick Blow 5/8" x 3/16"
Temperature range -10°C to +40°C
Humidity range 0% to 90% (non-condensing)
Communications RS485 at 307k2 baud, Infra Red Communications
8 Input 2 Output alternative specifications
Max. operating current 300mA
Outputs 2 relay, single pole changeover, 3 Amp
PTZ fuse 100mA resettable.
