Access Control Node
Security Grade Grade 3
SEAP Classification Class IV
Environmental class Class II indoor General
General
Mains Supply 230Vac + 10% - 15%
Power Consumption (quiescent) 45mA
Power Consumption (max) 150mA
Max current drain 1A
Memory Backup On-Board EEPROM
Cabinet Dimensions 233mm x 357mm x 80mm
Temperature Range -10°C to +55°C
Humidity Range 0% to 90% (non-condensing)
Fuses
Lock Supply 1A
Battery 1A
Auxiliary 1A
Reader Supply 1A
On-board Zones 2 dual end of line resistors monitored
On-board Outputs 2 single-pole changeover 2A relay
Front tamper On-board Microswitch (over-rideable)
Back tamper Terminal Connections, normally closed
Communications RS-485 at 307K baud and Infra-Red
Backup Power Supply Sealed 12V lead-acid battery to 6.5 Ah
Fuse (20mm) Type
Lock supply 1A 250v Anti Surge
Battery 1A 250v Anti Surge
Auxiliary 1A 250v Anti Surge
Reader supply 1A 250v Anti Surge
