Issue 4.5 August 2005 Technical Specifications 15- 19
Intellibell
Security Grade Grade 3
PCB Dimensions 150mm x 118mm
Display Type 2-Digit 7-segment
Input Voltage 11.4 - 15Vdc
Stand-by Battery 8.4 Vdc
Current Consumption (at 12.5Vdc) 100mA (quiescent)
700mA (sirens on)
500mA (speaker on)
20mA (power down)
Operating Temperature -10°C to +40°C
Humidity Range 0-95% (non-condensing)
Inputs 1 on-board zone monitored via the data line.
("Tamper","Test", "Detect" or "Control").
Outputs 4 output functions (controlled by panel outputs).
Audible Sounders Standard version -Piezo Siren (x2).
VAB version - Speaker (12W 8ohm)
Visual Indicators Strobe & "System Active" LED.
Test Features Programmable Stand-by Battery test.
Sounder, Strobe, and Battery test (output controlled).
Cabinet
Dimensions 365mm x 215mm x 85mm.
Material Inner & Outer 2mm steel skin.
Tamper Protection Lever Microswitch (x2).
Foam Ingress Detection Infra-red Beam (x2).
Drilling Detect "Drill Detect" option.
