15 - 8
RKD Node
Security Grade Grade 3
SEAP Classification Class IV
Environmental class Class II indoor General
PCB dimensions 122mm x 175mm x 23mm
Keypad dimensions 175mm x 120mm x 75mm
Minimum operating voltage 9.5V
Maximum operating current 300mA
Quiescent current 100mA
2 on-board zones Dual 2K2 (US: 1k,470) end-of-line resistors
Outputs
Relay Single pole changeover, 1 Amp
Display 2-line 48 character backlit liquid crystal display. Backlight intensity and
viewing angle are programmable.
Keypad 20 key backlit keypad
Tamper Front and Back tamper provided, each monitored separately
Memory backup Data stored in EEPROM and can be examined on display
Temperature range -10°C to +40°C
Humidity range 0% to 90% (non-condensing)
