Issue 4.5 Aug 2005 Network Router 13-7
Using the Network Router
Each Network Router has 10 LEDs on the front panel – see Frontplate diagram on page 13-3.
● STATUS: This LED blinks when the master communicates.
● Power LED: This is on once the network is powered up.
● Channel 1..8: This LED blinks when either the master communicates or the slave responds.
Note The Network Router will not operate correctly if the slave output(s)/3GS panel(s) do not have unique
addresses.
