Europlex 3GS - Page 60

Nodes 5-22
Diagnostic Menu: 6 and 8
Output Nodes
This menu provides you with data on the 6
and 8 Output nodes’ current configuration
and allows monitoring of node and PSU
parameters. This information includes
inputs, outputs, fuse, and tamper status.
It can be utilised to interrogate the status of
the node without having to remove the
cabinet lid, thus avoiding interfering with
cables and the need to use a voltmeter for
measuring node voltage and currents.
It can be accessed using the HHT infrared.
Alternatively, the same node information
can be accessed through the Node
Configure menu - Monitor submenu. See
Node Configure->Nodes->Information-
>Monitor in 3GS Programming for further
information.
For further information on HHT menus, see
Hand Held Terminal in 3GS Peripherals.
To scroll back
To scroll forward
through menu
UNSET
PART
I/O 8I 1O 00000000230
V1.11 15Apr99 002 1 2
I 01 = 2185 I 02= 2221
Z0 -C Z0 -C
I 07 = 2185 I 08= 2221
Z0 -D Z0 -D
I 05 = 3000 I 06= 3000
Z0 -D Z0 -D
I 03 = 2185 I 04= 2150
Z0 -C Z0 -C
TAMPER OK 12.7V
FUSE OKAY 000mA
On-board Input / Output
Serial Number
Node I D
Currrent Date
DC Supply Voltage
Output State
Output Type
Input 1 Analog Resistance Value
Input 1 State
O = Open
C = Closed
S = Short
D = Disconnected
DC = DC Substit ution
4400
2200
<1400
30000
Vari abl e
Input 1 Assigned Zone
Software Version
Tamper Switch(s) Status
01=ON
07
Press
to toggle output
displayed
ON/ OFF
DAYS RUNNING = 37
#
Number of days the node has been
continuously powered up
