260
MIDSECTION
STERN BRACKET, 40 – 60 HP MANUAL TILT
Drive the steering frict ion bushing up and out of
the swivel bracket.
Remove t he thrust rod fro m the stern b rackets.
Remove on e tilt tube nut, and remo ve tilt tube
from the ste rn bracket s and swivel bracket.
Remove the port and st arboard stop link screws
and nuts from the stern brackets.
Remove the two st ern bracket flange screws a nd
separate the stern bracket s from the swive l
bracket.
Place the tilt/ru n lever in the RUN positio n.
Loosen the bellcrank setscrew.
Remove the tilt/run lever, port stop link, and bush-
ing from the swivel bracket.
COA2974
1. Thrust rod
2. Tilt tube nut
3. Stop link screw and nut
COA2991R
3
1
2
1. Flange screws COA2992
1. Bellcrank setscrew COA2976
1. Tilt/run lever
2. Port stop link
3. Bushing
002204
1
1
3
1
2
