RECOIL STARTER ASSEMBLY
14
inner loop of t he spring in the slot of the pulley,
and install the pulley in the starter housing.
Place the friction plate spring washer between the
two frictio n plate s on the pulley hub. Secu re the
friction plate and friction plate spring washer with
the pulley lock ring.
Make sure the starter pawl bushing is installed in
the pulley. Apply Triple-Guard grease or Lubriplate
777 to boss of t he st arter pawl. Pla ce spring
washer on the boss of the starter pawl. Place the
starter pawl in the pulley.
Place th e st arter hou sing sp ring in t he st arter
housing.
Install the st arter p awl plate retu rn sp ring on th e
starter p awl pla te. Press the other e nd of sprin g
on the boss of the pulley. Position the starter pawl
plate on the pulley.
Clean thread s of th e st arter p awl plate ret aining
screw and nut to remove adhesive.
1. Inside loop
2. Slot
COA1365
1. Friction plate spring washer
2. Friction plates
34854
1. Lock ring
2. Spring washer (under starter pawl)
3. Spring
COA1361
1. Spring
2. Plate
46767
