DMP 128 FlexPlus • Configuration Tools 91
Organize Building Blocks
Extron building blocks are a quick configuration tool that can significantly reduce
configuration time. A building block is a collection of processor and gain settings for an input
or output processing chain. Building blocks have been built by Extron based on extensive
use and testing with each intended application or specific device. The Organize Building
Blocks
dialog box allows users to organize building blocks to their preference, import new
building blocks, export existing building blocks, delete building blocks, and restore default
building blocks that may have been deleted by the user. Building blocks in the Organize
Building Blocks
dialog are organized into folders for easily locating building blocks for a
multitude of applications.
Select Tools > Organize Building Blocks to open the Organize Building Blocks
dialog box.
1
Export Building Blocks File Button
4
Restore Default Building Blocks Button
2
Import Building Blocks File Button
5
New Folder Button
3
Delete Building Block Button
6
Building Blocks Panel
Figure 151. Organize Building Blocks Dialog Box
1
Export Building Blocks File Button — Click the button to export the selected
building block file to be saved to a disk.
NOTE: Building block files have an XML extension.
2
Import Building Blocks File Button — Click the button to browse the computer
for building block files to import to DSP Configurator.
3
Delete Building Block Button — Click the button to delete the currently selected
building block.
figure 141. Organize Building Blocks Dialog Box
