DMP 128 FlexPlus • Installation 9
Hardware Reset Modes
NOTE: The reset modes listed below close all IP connections, Telnet connections, and
sockets.
Mode 1 — Firmware Reset
Hold the Reset button while applying power to restore the unit firmware back to the default
factory firmware. This recovers a unit that has incorrect code or updated firmware running.
All user files and settings are maintained.
Mode 4 — IP Reset
With power on, press and hold the Reset button until the reset LED blinks twice
(~6 seconds). Release the button and, within 1 second, press it again to reset all IP address
settings to factory default.
The following changes take place:
• ARP program capability is enabled
• Sets IP back to factory default (192.168.254.254)
• Sets subnet mask back to factory default (255.255.255.0)
• Sets gateway back to factory default (0.0.0.0)
• Resets LAN 2 settings (V-model only)
• Turns DHCP off
• Sets digital I/O port mapping back to factory default
If a second momentary press does not occur within 1 second, Mode 4 is exited.
Mode 5 — Factory Default Reset
With power on, press and hold the Reset button until the reset LED blinks 3 times
(~9 seconds). Release the button and, within 1 second, press it again to return the
DMP128FlexPlus to factory default conditions.
The following changes take place:
• Sets all IP settings back to factory default (see Mode 4 above)
• Mix-points are set to unit gain (0 dBFS) and the following connections are made
• Input 1 is routed to output 1
• Input 2 is routed to output 2
• Input 3 is routed to output 3
• Input 4 is routed to output 4
• Input 5 is routed to output 5
• Input 6 is routed to output 6
• Input 7 is routed to output 7
• Input 8 is routed to output 8
• All audio inputs are set to unity gain
• All outputs are unmuted and set to unity gain
• Any inserted or active DSP is removed
• All preset and group master memory is cleared
