DMP 128 FlexPlus • Dante Controller 118
Dante Controller Operation
Dante Transmitters and Receivers
A Dante network is comprised of transmitters that output digital audio onto the Dante
network and receivers that receive digital audio input from the Dante network.
• Transmitters output digital audio from the device onto the audio network.
• Receivers take in digital audio from the audio network into the device.
DMP 128 FlexPlus Transmitters and Receivers
In the DMP 128 FlexPlus, the line output and EXP output channels are Dante transmitters
because their audio output is transmitted onto the Dante network. Routing an analog
output to the Dante network allows the signal to be output on both analog and Dante
simultaneously, the same is true for the EXP outputs.
The DMP 128 FlexPlus EXP input channels are Dante receivers because they receive digital
audio signal from the Dante network that can then be routed and mixed into the
DMP 128 FlexPlus mix matrix.
Dante Routing Operation
Dante Controller is used for all network signal routing of transmitters and receivers for
Dante-enabled devices. The DMP 128 FlexPlus transmitters and receivers are available
in Dante Controller for routing to other Dante devices (see Dante Transmitters and
Receivers above).
Routing Devices
After the DMP 128 FlexPlus is configured, the channels can be routed to the other Dante
devices on the audio network. Channels transmitted to the network or received from the
network are routed using the Dante Controller Routing tab on the Network View page
(see figure 184 on the next page). The transmitters, listed horizontally along the top of
the screen, and the receivers, listed vertically down the left side, form a matrix whose
intersections are the connection points between the receivers and transmitters.
• To make a receiver-to-transmitter connection, click once on an intersection.
• To remove a connection, click on the icon at the intersection.
