DMP 128 FlexPlus • Configuration Tools 83
• USB communications mute group
• USB 2 L
• USB 2 R
NOTE: It is recommended that both left and right USB audio channels be included
in the control groups.
Assigning USB Control Groups
To assign the USB communication audio controls:
1. Use the Gain Group drop-down in the USB 1 Control field set to select the USB
communications gain group containing the Aux inputs with USB 1 L and USB 1 R
assigned.
2. Use the Mute Group drop-down in the USB 1 Control field set to select the USB
communications mute group containing the Aux inputs with USB 1 L and USB 1 R
assigned.
To assign the USB playback audio controls:
1. Use the Gain Group drop-down in the USB 2 Control field set to select the USB
communications gain group containing the Aux inputs with USB 2 L and USB 2 R
assigned.
2. Use the Mute Group drop-down in the USB 2 Control field set to select the USB
communications mute group containing the Aux inputs with USB 2 L and USB 2 R
assigned.
After all controls have been assigned, test the controls and make any adjustments to group
members or USB control selections in the Configure USB Control dialog. Click Close
to close the dialog.
Configure Internal Triggers
The Configure Internal Triggers option opens the Internal Trigger Setup dialog. This dialog
allows for the configuration, testing, and application of internal triggers.
NOTE: The Configure Internal Triggers option is only available when
connected Live to a VoIP-enabled audio product with a TCP/IP connection.
Figure 140. Configure Internal Triggers Dialog
