DMP 128 FlexPlus • Configuration Tools 92
4
Restore Default Building Blocks Button — If default building blocks that come
installed with DSP Configurator are deleted, click the button to restore them.
NOTE: Only the default building blocks can be restored with this function. User
created building blocks are not restored if deleted.
TIP: To avoid accidentally deleting user created building block files, once they are
created, export them to a safe location on the disk. This creates a backup copy of
the building block file, should it be deleted by the user by mistake.
5
New Folder Button — Click the button to create a new folder that building blocks
can be dragged into. Upon creation, a default folder name is highlighted and a custom
name can be entered. Click a folder name twice to edit the folder name.
6
Building Blocks Panel — This panel contains folders and building blocks. Click and
drag building blocks to change their order or place them inside folders. Click a building
block name twice to edit the building block name. Click a folder name twice to edit the
name of the folder.
Device Settings
The Device Settings dialog box provides access to general settings of the
DMP128FlexPlus. Select Tools > Device Settings to open the Device Settings
dialog box. Device settings are only available when connected live to a device.
Within the Device Settings dialog box, the following tabs are available:
• Unit Info • IP Settings • Passwords
• Serial Settings • Date/Time • Dante Device
Unit Info
The Unit Info tab displays the unit name, firmware version, device model, device part
number, and device MAC address. Click in the Unit Name field to rename the device within
the listed naming parameters. Click Apply to save the changes.
Figure 152. Unit Info Tab
figure 142. Unit Into Tab in Device Settings Dialog Box
