DMP 128 • Remote Control and Configuration 123
Remote
Communication and
Control
This section describes how to control the DMP 128 FlexPlus with SIS programming and
covers the following topics:
• Connection Options
• Host-to-Device Communications
• Using the Command and Response Tables
• Command and Response Table for Basic SIS Commands
• Command and Response Table for DSP SIS Commands
• Command and Response Table for VoIP SIS Commands
• Object ID (OID) Number Tables
Connection Options
The DMP 128 FlexPlus Digital Matrix Processor can be remotely connected via a host
computer or other device (such as a control system) attached to the rear panel RS-232 port
or LAN port, or the front panel USB Config port.
The DMP 128 FlexPlus can be set up and controlled using SIS commands or DSP
Configurator software (see Installation on page4 for pin assignments and details on
the configuration and control port connections. For information on DSP Configurator, see
DSP Configurator Software on page10).
SIS commands can be executed using the Extron DataViewer application available from
www.extron.com. The host computer issuing the commands can be connected via the
following connections:
• RS-232 Port on the next page
• LAN Port on the next page
• USB Config Port on page125
