DMP 128 FlexPlus • Configuration Tools 67
Configuration Tools
This section contains information for configuring certain tools and options that are found
under the Tools menu in DSP Configurator and covers the following topics:
• Presets • Firmware Loader
• Groups • Organize Building Blocks
• Digital I/O • Device Settings
• Players • Options
• Macros • Expansion Bus
• Device Manager • Phone Dialer
• Connect to or Disconnect from Device
Presets
Preset options are available from the Tools menu.
Figure 116. Presets Options
1
Mark All Items — Marks all gain blocks, processor blocks, and mix-points in the main
workspace. Performing this function before saving a preset ensures every element in the
workspace is saved to the preset.
2
Save Preset — Saves the marked blocks and mix points of the current configuration
as a preset. When Save Preset is clicked, the following dialog box opens saying that
only the elements marked with a green outline are saved to the preset (see figure 118
below). This option is only available if items are marked.
Figure 117. Preset Save Message
3
Clear Marked Items — Unmarks all currently marked elements.
figure 108. Preset Options
figure 109. Preset Save Message
