DMP 128 FlexPlus • Installation 4
Installation
This section describes the installation of the DMP 128 FlexPlus and covers the following
topics:
• DMP 128 FlexPlus Models
• Mounting
• Rear Panel Features and Cabling
• Front Panel Features
• Hardware Reset Modes
DMP 128 FlexPlus Models
Model Description
DMP 128 FlexPlus C AT Dante Digital Matrix Processor with 12 AEC
DMP 128 FlexPlus C V AT Dante Digital Matrix Processor with 12 AEC and VoIP
Mounting
The 1U high, half rack width, 9.5 inch deep DMP 128 FlexPlus mounts in the following
manners:
• Rack mounting — Attach the DMP 128 FlexPlus to a standard 19-inch rack shelf.
The following Underwriters Laboratories (UL) guidelines pertain to the installation of the
DMP128 FlexPlus in a rack:
• Reduced air flow — Install the equipment in the rack so that the amount of air
flow required for safe operation of the equipment is not compromised.
• Mechanical loading — Mount the equipment in the racks so that uneven
mechanical loading does not create a hazardous condition.
• Circuit overloading — When connecting the equipment to the supply circuit,
consider the effect that circuit overloading might have on overcurrent protection
and supply wiring. Consider equipment nameplate ratings when addressing this
concern.
• Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to power supply connections other than direct
connections to the branch circuit (such as the use of power strips).
• Under-furniture mounting — Mount the DMP 128 FlexPlus under the surface of a
desk, table, or podium.
• Free-standing — Attach the four rubber feet provided with the device to the bottom of
the DMP 128 FlexPlus in the four corners and place the unit on furniture as desired.
NOTE: To mount the DMP 128 FlexPlus using an Extron mounting kit, see the
instructions provided with the kit.
