DMP 128 FlexPlus • DSP Configurator Software 41
6
Cancel Button — Reverts any changes made to the contained parameters back to
their states when the current instance of the Pre-mixer Gain dialog box was opened
and closes the dialog box.
7
Pre-mixer Gain Help Button — Opens the Pre-mixer Gain topic of the
DSPConfiguratorHelp file for further assistance in understanding operating the
Pre-mixer Gain dialog.
Aux Inputs
Eight Aux inputs are available with processing. These inputs can be assigned as one of the
following:
• Player inputs that play audio files stored in the DMP 128 FlexPlus internal memory (see
Player Input on the next page)
• USB inputs that receive audio via the rear panel USB audio port (USB Input on
page43)
• VoIP lines for use with a VoIP network (V-model only, VoIP Input on page43)
Figure 67. Aux Inputs Panel
Renaming an Aux Input
1. Click the input name field.
Figure 68. Aux Input Name Field
2. Delete or highlight the text and type the desired name.
Figure 69. New Aux Input Name
3. Press the <
Enter> key or navigate away from the field to confirm and apply the new
name. Press the <Down Arrow> key to navigate to and highlight the next name field.
Figure 70. Renamed Aux Input
NOTE: Follow the same procedure to edit an Aux input name.
figure 59. Aux Inputs Panel
figure 60. Aux Input Name Field
figure 61. New Aux Input Name
figure 62. Renamed Aux Input
