DMP 128 FlexPlus • DSP Configurator Software 42
Aux Input Building Blocks
Building blocks can be applied to all eight Aux input channels. These buildings blocks
function the same as the mic/line input building blocks (see Input Building Blocks on
page21 for more information on configuring Aux input building blocks).
Aux Input Processing
The input processing chain in DSP Configurator is visually represented by a string of blocks.
Each block contains a specific processor or type of processor. Aux Inputs 1 through 8
contain the following signal processing chain:
1. Aux Input Gain Block
2. Aux Input Filter Block
3. Aux Input Dynamics Block (2)
4. Aux Input Ducking Block
5. Aux Input Automix Block
6. Aux Input Pre-Mixer Gain Block
Aux Input Gain Block
By default, the Aux input gain block does not have an input source selected. Double-click
the block to open the input selection drop-down, presenting three options for each Aux
input source:
• Player — Plays audio files stored on the DMP 128 FlexPlus internal memory.
• USB — Receives audio input from the rear panel USB port.
• VoIP (V-model only) — Receives audio input from the VoIP network.
Player Input
Double-click the Aux input gain block and hover the mouse over Player... to display
the eight available players. If no audio file is assigned to the player, the player displays
[unassigned]. If an audio file is assigned to the player, the player displays the filename
(see Players on page75 for more information on configuring players). Select one of the
players to insert it as the source for the selected Aux input.
Figure 71. Aux Input Player Selection
Once a player is selected as an Aux input source, start and stop controls are available in
Live mode by right clicking the input gain dialog and hovering over
Player Control....
Figure 72. Player Start and Stop Controls
figure 63. Aux Input Player Selection
figure 64. Aux Input Player Selection
